GPS RTK GNSS CHCNAV I50

GPS RTK GNSS CHCNAV I50

Description:
The CHCNAV i50 GNSS receiver brings speed and accuracy in one easy-to-use GNSS solution to complete your surveying and construction projects efficiently.
Combined with CHCNAV LandStar 7 field software and HCE320 Android controller, the i50 is the perfect surveying solution for topographic and construction positioning tasks.

Key Features

• 634 Channels Full GNSS
• Extended Connectivity
• Flexible Work Modes</li>
• Rugged and Co
• mpact
• Extra Power

Specifications:

• Power
  Operating power: min. (V) 7.4
  Operating power: max. (V) 36
  Typical consumption (W) 4.2
  Internal power supply 7.4
  External power 9 – 36
  Operating time with internal power supply (hr) 12
  Certifications CE
• Environment
  Operating temperature: min. (°C)-40
  Operating temperature: max. (°C) 65
  Humidity resistance 95%
  Water sand and dust proof IP67
  Shock and vibration proof 2-meter pole drop
• Performance
  No. channels 432
  Tracked satellite signals GPS, GLONASS, Galileo, BeiDou, SBAS, QZSS
  SBAS differential signals L1
  Type of measurements RTK, PPK, Static
  Reacqisition time (s) <1s
  RTK Network Compatibility >99.9%
• Horizontal Uncertainty
  code: DGNSS/RTC (constant part) (m) 1.5
  code: DGNSS/RTC (variable part) (ppm) 3.0
  phase: RTK kinematic (constant part) (m)0.017
  phase: RTK kinematic (variable part) (ppm) 1
  phase: static post processing (constant part) (m)0.006
  phase: static post processing (variable part) (ppm) 0.5

Note:
*Harga Dapat Berubah Sewaktu – waktu tanpa pemberitahuan terlebih dahulu.
*Mohon tanya ketersediaan barang terlebih dahulu.
